one
Function introduction
one
. handheld box adopts
320*240
High resolution color screen, all Chinese operation interface, easy to learn and use.
two
, with drawing points, lines, polylines, 3D arcs
(
Space arc
)
, circle, runway, rectangle, coating, automatic rounding, irregular 3D spline
Curve and other graphic elements; Rich manual teaching functions and graphic preview functions.
three
With conditional jump function, and double
MARK
Point rotation needle alignment function.
four
It has skip function and can select multiple discontinuous instructions at the same time.
five
It has the function of command movement, and can move the edited command to the target position.
six
. it has the function of breakpoint execution, which can be executed from the specified point.
seven
With area array replication, offset operation, batch editing, single step operation,
I/O
Input and output functions.
eight
It has the functions of automatic execution, automatic reset, output setting, processing time timer, etc.
nine
There are four different wire drawing process options, which can solve the process problems such as wire drawing.
ten
, support
DXF
and
PLT
File import, automatic path optimization function.
eleven
After editing the action parameters, download the action parameters to the controller through the serial port, and then run offline independently. You can also save action parameters
To the handheld box for convenient calling; And it can copy and save graphics between devices.
twelve
The handheld box can store hundreds of processing files, and each file can support
eight thousand
Instructions, which can be called up when in use.
thirteen
Hardware
four
Gun channel control
four
Circuit general output
eight
Channel input
twelve
High speed pulse output; Control dispensing time accuracy
1ms
。
fourteen
Each action command has independent glue opening delay, glue closing delay, gun withdrawal height, independent glue closing function in advance, and flexible batch modification function
It can improve editing efficiency and solve the problem of glue stacking.
